HC-12 433MHz Long-Range Wireless Serial Transceiver Module (SI4463, 1km)
A drop-in wireless replacement for a serial cable: send data over UART up to about 1 kilometre in open space, with no pairing and no configuration to get started.
The HC-12 is one of the easiest ways to add long-range wireless to an Arduino, ESP32 or any microcontroller project. It talks plain serial (TX/RX), so anything you can print over a UART, you can send across a field, a building or a street. Two modules out of the box are already on the same channel — power them up, wire TX to RX, and they just talk. When you need more, the on-board SI4463 chip lets you change channel, baud rate and transmit power with simple AT commands.
Key specifications
- Frequency: 433.4–473.0MHz (ISM band), 100 selectable channels
- Range: up to ~1000m in open space (line of sight, at the lowest baud rate)
- Interface: UART serial — TX, RX, plus a SET pin for AT-command configuration
- Supply: 3.2V–5.5V — works directly on both 3.3V and 5V boards
- Max transmit power: 100mW (20dBm), adjustable
- Receiver sensitivity: down to −117dBm (at 5000bps over the air)
- Chipset: Silicon Labs SI4463
- Includes: the module plus a 433MHz helical spring antenna
Pinout
- VCC — 3.2–5.5V power in
- GND — ground
- RXD — serial data in (to the module)
- TXD — serial data out (from the module)
- SET — pull low to enter AT-command / configuration mode
- ANT — solder the supplied spring antenna here
What people build with it
Wireless sensor nodes and weather stations, remote-controlled robots and cars, gate and door controllers, drone telemetry, RS‑485-style long links without the wiring, and any project where Bluetooth or WiFi simply does not reach far enough. Because it is transparent serial, it is also the quickest way to get two Arduinos talking without writing any radio code.
Tip: for reliable range, run both modules at the same baud rate and channel, keep the antenna vertical, and drop the baud rate down (e.g. 1200bps) when you want maximum distance.
